6040 M
Outer diameter (D): 310 mm
Inner diameter (d): 200 mm
Width (B): 51 mm
Basic dynamic load rating : 216 KN
Basic static load rating: 245 KN
Product Description
Outer diameter (D):
310 mm
Inner diameter (d):
200 mm
Width (B):
51 mm
Basic dynamic load rating :
216 KN
Basic static load rating:
245 KN
Fatigue load limit (Pu):
6.4 KN
Reference speed :
4300 r/min
Limiting speed :
3600 r/min
Shoulder diameter (d1):
235 mm
Shoulder diameter (d2):
-
Shoulder diameter (d1):
275 mm
Recess diameter (D2):
-
Chamfer dimension (r1,2):
2.1 mm
Mass:
14 kg
