62305 2RS1
Outer diameter (D): 62 mm
Inner diameter (d): 25 mm
Width (B): 24 mm
Basic dynamic load rating : 22.5 KN
Basic static load rating: 11.6 KN
Product Description
Outer diameter (D):
62 mm
Inner diameter (d):
25 mm
Width (B):
24 mm
Basic dynamic load rating :
22.5 KN
Basic static load rating:
11.6 KN
Fatigue load limit (Pu):
0.49 KN
Reference speed :
-
Limiting speed :
7500 r/min
Shoulder diameter (d1):
36.6 mm
Shoulder diameter (d2):
-
Shoulder diameter (D1):
-
Recess diameter (D2):
52.7 mm
Chamfer dimension (r1,2):
1.1 mm
Mass:
0.32 kg
