6252 M
Outer diameter (D): 480 mm
Inner diameter (d): 260 mm
Width (B): 80 mm
Basic dynamic load rating : 390 KN
Basic static load rating: 530 KN
Product Description
Outer diameter (D):
480 mm
Inner diameter (d):
260 mm
Width (B):
80 mm
Basic dynamic load rating :
390 KN
Basic static load rating:
530 KN
Fatigue load limit (Pu):
11.8 KN
Reference speed :
2600 r/min
Limiting speed :
2400 r/min
Shoulder diameter (d1):
337 mm
Shoulder diameter (d2):
-
Shoulder diameter (D1):
403 mm
Recess diameter (D2):
-
Chamfer dimension (r1,2):
5 mm
Mass:
65.5 kg
