6348 M
Outer diameter (D): 500 mm
Inner diameter (d): 240 mm
Width (B): 95 mm
Basic dynamic load rating : 442 KN
Basic static load rating: 585 KN
Product Description
Outer diameter (D):
500 mm
Inner diameter (d):
240 mm
Width (B):
95 mm
Basic dynamic load rating :
442 KN
Basic static load rating:
585 KN
Fatigue load limit (Pu):
12.9 KN
Reference speed :
2600 r/min
Limiting speed :
2400 r/min
Shoulder diameter (d1):
331 mm
Shoulder diameter (d2):
-
Shoulder diameter (D1):
409 mm
Recess diameter (D2):
-
Chamfer dimension (r1,2):
5 mm
Mass:
97 kg
